Double Screw Plastic Pipe Extrusion Machine / Pvc Water Supply Pipe Making Machine
Plastic Pipe Extrusion Line / PVC Water Supply Pipe Making Machinery / Plastic PVC Pipe Extrusion Process
Quick Details:
1. Description
Raw material: PVC resin+ other ingredients
Final Products: PVC water/sewage pipe
Pipe Diameter: 16-630mm
2. Main Electricity Brand:
Main Motor: famous brand in china
Frequency control: ABB
Bearing : NSK, Japan
Contactor: Simens
Description:
Plastic Machinery 16-63mm PVC Pipe Production Line for Water Supply Ce Certificate
Performance & Advantages:
1. Plastic Machinery 16-63mm PVC Pipe Production Line for Water Supply Ce Certificate is mainly used in the manufacture of the plastic PVC pipe with various tube diameters and wall thickness in the aspects such as the agricultural and constructional plumbing, cable laying etc.
2.This set is composed of the conical twin-screw extruder, vacuum calibration tank, printer, haul-off, cutter, stacker, etc.The extruder and extractor adopt the imported AC frenquncey control device.The vacuum pump and the main motor adopt the famous brand.
3. The drawing machine includes two-claw type, three-claw-type , four-claw type ,six-claw type ,eight-claw type, etc. Saw cutting or planet cutting can be applied, it is additionally applied with length measuring meter and thickness increasing device, the property of machine group is reliable , the production efficiency is high.
Technical parameters:
| Model | Screw diameter | L/D | Pipe range | Capacity | Main motor power | Total power | Line length |
| U-PVC63 | 51/105 | 14.5:1 | 16-63 | 80-120 | 18.5 | 50 | 22 |
| U-PVC160 | 65/132 | 14.5:1 | 75-160 | 200-250 | 37 | 100 | 22 |
| U-PVC250 | 65/132 | 14.5:1 | 110-250 | 200-250 | 37 | 120 | 30 |
| U-PVC315 | 80/156 | 15.25:1 | 160-315 | 300-400 | 55 | 200 | 30 |
| U-PVC450 | 80/156 | 15.25:1 | 200-450 | 300-400 | 55 | 220 | 36 |
| U-PVC630 | 92/188 | 17.86:1 | 315-630 | 400-800 | 90 | 350 | 42 |
Competitive Advantage:
1. We give you suitable suggestions according to your actual need.
2. CE ISO9001 Certificate
3. Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
4. Free operation training and technology formula transfer
