Recycled Water Ring Granule Single Screw Extruder , Waste Granule Machine for Flakes
QUICK DETAIL :
1. High efficiency
2. Low power consumption
3. Highly automatically
Description:
This raw materials like waste films of HDPE and LDPE are extruded through the extruder, and then are cooled through wind and cut hotly into granules, featuring in fine quality, bubble free and moisture free. The machine is equipped with a forced feeder, fast mesh changer and automatic rhermocontroller.
By regulating the rotation speed of extruder and altering screw structure it is applicable to manufacture different plastic profile, like PE PP PS ABS PVC and polyolefin Modificationand granulation: Being applicable to the different plastic material co-mixing, modification and reinforcing granulation.
With rotation feeder, the pe pp flakes will get into the screw even and continuously, our motors, tempreture controller and inverters are made by world famous brand, such as Siemense, Omron, RKC, FUJI, and so on. Our screw and barrels are 38CrMoALA, nitrogen treatment. With double screen exchanger, you can exchange the screen without stopping the machines.
This PET Strand Pelletizing Machine/pet plastic granulation line is mainly used for the compounding, filling, reinforcing, pelletizing and modification of PET granules, which is specially designed by KOOEN machinery.
Advantages about this production line , simple process , automatic temperature control , low power consumption, non-pollution , high capacity.
Applications:
1. Material types: printed pp film, pe film, ldpe film, hdpe film, lldpe film, bopp film,waste agricultural film,bags,crushed flakes,rigid flakes etc
2. Special design for two kinds of material:film(soft)&flakes(hard)
Specifications:
| Model | Screw diameter
(mm) | L/D | Screw rotation speed (r/min) | Max. extruding
Capacity
(kg/h) | Motor power
(kw) | Heating zone |
| SJ-45 | 45 | 33:1 | 73 | 60 | 28/35 | 3 |
| SJ-50 | 50 | 33:1 | 90 | 120 | 37/45 | 3 |
| SJ-65 | 65 | 33:1 | 90 | 220 | 55/75 | 4 |
| SJ-75 | 75 | 33:1 | 90 | 350 | 90/110 | 4 |
| SJ-90 | 90 | 33:1 | 90 | 500 | 160/185 | 5 |
| SJ-120 | 120 | 33:1 | 80 | 750 | 280/315 | 5 |
| SJ-150 | 150 | 33:1 | 80 | 1000 | 355/385 | 5 |
Competitive Advantage:
1. Lower power consumption
2. More stable output
3. Smooth & full pellets
